What a car air filter is and how it works.

Automobile air filter is to remove particulate impurities in the air in the car, automobile air conditioning filter can effectively reduce pollutants through the heating ventilation and air conditioning system into the car, prevent the inhalation of harmful pollutants.

Introduction To Air Filter

Car air filters can bring a cleaner interior environment to cars. Automobile air filter belongs to automotive supplies, which is composed of filter element and shell. Its main requirements are high filtration efficiency, low flow resistance, can be used continuously for a long time without maintenance.

The Role Of Air Filters

Automobile air filter is mainly responsible for removing particulate impurities in the air device. Piston type machinery (internal combustion engine, reciprocating compressor, etc.) work, if the inhalation of air containing dust and other impurities will aggravate the wear of parts, so it must be equipped with an air filter. Air filter is composed of two parts: filter element and shell. The main requirements of air filter are high filtration efficiency, low flow resistance and long continuous use without maintenance.

The car engine is a very precise part, and the smallest impurity will damage the engine. Therefore, before entering the cylinder, the air must be carefully filtered by the air filter before entering the cylinder. Air filter is the patron saint of the engine. The state of air filter is related to the life of the engine. If the dirty air filter is used in the car driving, it will make the engine air intake insufficient, so that the fuel combustion is not complete, resulting in unstable engine work, power decline, fuel consumption increase phenomenon. Therefore, the car must keep the air filter clean.

Classification Of Air Filters

(1) According to the working principle, there are inertia type, filter type and compound type.
(2) According to the structure, there are dry type and wet type.

Structure Of Air Filter

Air filter is generally composed of air inlet guide pipe, air filter cover, air filter shell and filter element.

Working Principle Of Air Filter

1. Dry Inertia Air Filter

Dry inertia air filter is composed of dust cover, diversion sheet, dust outlet, dust collection cup and so on. Its working principle is to make use of the suction generated by the cylinder in the intake stroke, so that the air filter inside and outside the pressure difference, the external air under the action of pressure at a higher speed into the air filter, the dust mixed in the air is thrown to the dust collecting cup, complete the air filtration.

2. Wet Inertia Air Filter

Wet inertia air filter, also known as oil bath filter, is mainly composed of central pipe, oil pool and so on. Its working principle is that the air enters the filter along the central pipe at a high speed down, plunges to the oil surface of the oil pool after the direction of movement suddenly changes to the upward, and produces rotating movement. At this time, part of the larger dust due to inertia action is too late to reverse upward with the air and is attached to the oil to complete the filtration of the air.

3. Dry Filter Type Air Filter

Dry filter type air filter is mainly composed of paper filter element and sealing gasket, its working principle is that when the air enters the filter through the paper filter element, so that the dust in the air is separated by the filter element or adhered to the filter element.

4. Wet Filter Type Air Filter

Wet filter type filter is mainly composed of metal filter mesh immersed in oil, its working principle is that the air filtered by oil bath is blocked when the fine dust particles are kept in the metal filter mesh immersed in oil, and the adhesion part of dust particles randomly drops to the oil pan.

The Function Of Air Filter

Filter out impurities or dust in the air, so that clean air into the cylinder.
